by Alessandro La Ferlita, Naval Architect

Ultimate hull girder strength represents the maximum capacity, of the hull girder beyond the structure fails.

In fact, if the vertical bending moment applied overcomes a certain maximum value, the ship can collapse (Figure 1) due to different phenomena as buckling and progressive collapse [1] of the compressed part.

Instances are famous cases of the oil tanker “Energy Concentration” that happened in 1980 and the container vessel “MOL COMFORT” in 2013.

Figure 1 Collapse of “Energy Concentration” [2]

The estimation of the ultimate strength plays an important role in structural safety and for reliability in terms of loads during the life of the vessel.

In general, the ultimate hull girder capacity considers the evaluation of the overall strength by summing up the general load capacities of individual elements such as plates, stiffeners, girders within the cross-section.

Methods for determining the ULS

Several rule models can be used for calculating the ultimate strength.

1) Smith method (Iterative approach)

2) ISUM (Idealized Structural Unit Method)

3) Non-linear FEA.

The first method is quite well known and prescribed by IACS.

The original idea comes from Smith at the end of 70’s which developed a simplified method to evaluate the ultimate strength basing his approach on the following assumptions [3]:

• the section of the ship to take into account is between two stiffened frameworks and consists of all the structural elements that contribute to longitudinal strength
• the collapse section remains plane when the curvature tends to increase or decrease;
• the behavior of the material constituting the resistant section is ideal elastic-plastic characterized by the load end shortening curve;
• the structural section is considered to consist of j elements (j → discrete number of elements) whose structural behavior is independent when the curvature is acting on the section.

The main steps (Figure 3) to consider for the procedure are the following [3] [4]:

1. subdivision of the main cross-section in a defined type of element correspondingly into:
• Hard corner Element, which is generally constituted by two plates that do not lie in the same plane: one is horizontal and the other is vertical.
• Longitudinally stiffened plate element, with attached plating up to the midpoint between adjacent stiffeners on each side.
• Transversely stiffened plate elements, which are typical geometrical areas between stiffener elements and hard corner elements (Figure 2).

Figure 2 Subdivision – Hard Corner/Transversally stiffened Plate Elements/ Longitudinally stiffened plate element

Figure 3 Description of the Smith Method [3]

2. The stress-strain relationships of individual elements are carefully considered and obtained, taking into account: the influences of yielding, buckling, and the initial Neutral axis.

1. Figure 4a Behavior curves

Regarding this second step, the stress properties of each element are defined using different curves that describe the relationship between the axial load and displacement.  In general, it is possible to distinguish them according to their behavior (figure 4a) [5]:

(a) elastic without buckling;

(b) elastic-perfectly plastic without buckling;

(c) buckling/yielding without strength reduction beyond the ultimate strength;

(d) buckling/yielding with strength reduction beyond the ultimate strength.

This last behavior is quite realistic and its capacity decreases after its maximum value has been obtained.

In general, those curves could be determined by using empirical approaches or by nonlinear finite element method, using for example some software as ANSYS or ABAQUS. Nevertheless, direct methods are given by DNV GL which suggests using a specific formula for obtaining the corresponding stresses as shown in table 1.

Table 1 Mode of Failure [6]

 Element Mode of failure Lengthened stiffened plate element or stiffener element Elasto-plastic collapse Shortened stiffener element Beam column buckling Torsional buckling Web local buckling of flanged profiles Web local buckling of flat bars Shortened stiffened plate element Plate buckling

3. Forces are derived by multiplying the stress by the area of the element considered. The final sum of the forces above the neutral axis should be equal to the sum of the forces below the neutral axis; If this condition is not satisfied, it means that the initial position is shifted and a new one should be searched;

4. Verification that the new neutral axis (which guarantees the equilibrium of stresses) differs with a low tolerance value in respect to that one assumed at begin of the procedure. If this condition is not fulfilled, it is necessary to reiterate all the process basing the calculation on the last neutral Axis obtained;

5. In case the previous step is satisfied, it is possible to calculate the bending moment. After that, it would be necessary to increase the curvature of a certain delta of increment;

•

Residual ULS

The determination of the ULS plays an important role especially when the ship results damaged and the salvage operation is needed.

In fact, grounding or collision can lead to a reduction in the effectiveness of the structural elements and consequently to the reduction of ultimate strength.

Figure 4 Damage due to  grounding [5]

In such circumstances, by neglecting the elements which belong to the cross-section (Figure 4) which do not carry anymore the longitudinal strength, it is possible to calculate the ULS (Figure 5).

In this context, the methods before mentioned could be applied, but paying attention to the symmetry/asymmetry of the damage

Figure 5 Residual ULS for different damaged scenario  vs Intact ULSS [6]

RD Diagram

Paik et al. [5] proposed an innovative method for assessing the safety of a ship which has suffered damage grounding through the application of R-D (Residual Damage) Diagram.

Figure 6 Residual damage diagram  [7]

They are obtained in the following way.

First of all, the characteristics of the ships, including geometry, dimensions, and material properties are defined. Then a limited number of probable damage scenarios representing all possible scenarios can be selected by a

probabilistic approach.

In practice, it means that a small number of probable scenarios for possible accidental or in-service damage are selected using for instance a sampling technique in which the random variables affecting the damage are probabilistically characterized.

Afterward, the GDI (grounding damage index) is defined for describing the damage severity for each of the considered scenarios.

The residual strength of the ships in the grounding damage scenarios is then calculated by using a simplified approach or by applying more complex methods, such as non-linear FEM (Finite Element Method).

Finally, the R–D diagram is established based on these calculations performed.

Furthermore, the GDI concept can be applied to determine the acceptance criteria for grounding strength performance [9].

For example, IMO (International Maritime Organization) specifies requirements that the ultimate longitudinal strength of all newly built ships be no smaller than 90% of the strength performance.

In general, those kinds of diagrams will be very useful for a first-cut assessment, immediately after it has been suffered a grounding, by knowing the damaged area.

Bibliography

 [1] Ö. E. Bayraktarkatalb, “Effects of Key Factors on Hull Girder Ultimate Strength Estimation by Progressive Collapse Calculations,” Latin American Journal of Solids and Structures, pp. 2371-2392, 2016. [2] “www.shipspotting.com,” [Online]. Available: http://www.shipspotting.com/gallery/photo.php?lid=1688178. [3] DNVGL-CG-0128, “APPENDIX E HULL GIRDER ULTIMATE BENDING CAPACITY BY MULTI-STEP METHOD,” 2018, pp. 125-136. [4] Soares, A. W. Hussein & C. Guedes, Design Equation for the Ultimate Capacity of Double Hull Tankers Designed According to the Common Structural Rules, Lisboa, Portugal: Centre for Marine Technology and Engineering (CENTEC), Technical University of Lisbon, 2008. [5] M. F. Tetsuya Yao, “PROGRESSIVE COLLAPSE BEHAVIOR OF HULL GIRDER UNDER,” in Buckling and Ultimate Strength of Ship and Ship-like Floating Structures, Kidlington, Oxford, United Kingdom : Butterworth-Heinemann is an imprint of Elsevier Á, 2016, pp. 321 – 336 – 348 – 353. [6] DNVGL-CG-0128, “APPENDIX E HULL GIRDER ULTIMATE BENDING CAPACITY BY MULTI-STEP METHOD,” DNVGL-CG-0128, 2018, pp. 125-136. [7] J. K. Paik,D. K. Kim,P. T.Pedersen,H. Kim , “DEVELOPMENT OF A RELATIONSHIP BETWEEN RESIDUAL ULTIMATE LONGITUDINAL STRENGTH VERSUS GROUNDING DAMAGE INDEX DIAGRAM FOR CONTAINER SHIPS,” Proceedings of the ASME 31st International Conference on Ocean, Offshore and Arctic Engineering OMAE, vol. 2, pp. 1-10, 2012. [8] Ji-Myung Nam and Joonmo Choung , “Residual Longitudinal Strength of a VLCC Considering Probabilistic Damage Extents,” Proceedings of the Twenty-second (2012) International Offshore and Polar Engineering Conference , 2012. [9] Do Kyun Kim, Preben Terndrup Pedersen, Jeom Kee, “Safety guidelines of ultimate hull girder strength for grounded container ships,” Safety Science, vol. 59, pp. 46-54, 2013.

Please do checkout TheNavalArch’s simple-to-use and effective calculator for Hull Ultimate Strength – called the Hull Grounding Damage Index (GDI) calculator
