Introduction
Marine transport is the backbone of the global trade and reasonably can be considered to be the artery of the global manufacturing supply chain, as more than four fifths of the world merchandise trade by volume is carried by sea. Undoubtfully, the working horse of merchant shipping industry is the Bulk carrier’s fleet, which with its 842 438 thousand deadweight is forming 42,6 % of the world’s tonnage has transported 5230 million tons various bulk commodities during 2018 as per UNCTAD Review of Maritime Transport .
An essential part of each merchant seatrade is the correct determination of the cargo loaded/discharged from/to the transporting unit. Considering the specifics of the bulk cargo commodities, historically the industry has recognized the following methods for weight determination:
 Various types of shore weighbridges – The accuracy is unlikely to be better than within 0.2% and in case conveyor/weighbelt systems are used no better than ±2%.
 Draft survey – Generally well prepared and meticulous draft survey can achieve an absolute accuracy of ±0.5%.
 Determining the volume of the cargo in holds and applying the cargo stowage factor – The accuracy is questionable and this method provides no more than an approximate estimation.
In this article, the methodology, calculation, and common errors of a draft survey will be discussed. The matter is well known, and various articles, publications and guidelines have been issued during the years from Master Mariners, Naval Architects, P&I clubs and even from the United Nations’ Economic and Social Council.
1. Draft survey theory
Draft (or draught) survey is based on the Archimedes Principle, which states that anything that freely floats will displace an amount, that is equal to its own weight, of the liquid it is floating in. It is obvious that the quantity of water displaced will not only be the weight of the cargo on board but also include:
 Vessel’s lightship weight;
 Ballast water;
 Fresh water;
 Bunker (fuel, diesel and lubricating oils);
 Bilge/sludge and other known liquids;
 Other known cargo(s);
 Vessel’s constant which generalize provisions, stores, crew, residual unknown weight etc.
Briefly, the weight of the ship is determined both before and after loading/discharging and allowances made for all known deductibles. The difference between these two weights, known as net displacement , is the weight of the cargo loaded or discharged.
2. Draft survey methodology
2.1 Vessel’s condition
In order to prove accurate result of the draft survey the vessel has to comply with the following:
 To be upright in case not possible, the list must not be more than 0,5⁰;
 Minimum possible trim and in all cases, within the corrections covered in the ship’s tank sounding tables;
 Draft marks to be well visible, painted and its distance to the forward or aft perpendicular should be known;
 Means of access in order to check draft from seaside to be available;
 The vessel has to be provided with approved hydrostatic and tanks sounding tables;
 Minimum ballast tanks to be slack;
 All sounding pipes to be unobstructed and capable of serving their intended purpose;
2.2 Draft
The most essential part of each draft survey is the correct observation of all of the vessel’s drafts.
But as every experienced draft surveyor knows, the above is easy to be said and hard to be accomplished due to following factors:
 Due to the height of the jetty the present draft could not be seen horizontally or in some cases could not be seen at all.
 Draft marks are positioned under or in close proximity to jetty’s fenders.
 Ripples or waves in the port basin due to passing vessel, insufficient break water protection etc.
 Insufficient illumination during the night;
 Draft marks missing or in poor condition;
 Vessel’s rolling or pitching;
 Change of draft due to strong current;
 Change in draft due to thermal expansion of the vessel’s hull due to the solar heat radiation;
Figure 1. Typical draft mark

Figure 2. Draft mark in bad/unreadable condition

2.2.1 Correction of draft to perpendiculars
The hull volumetric characteristics are based on some theoretical lines and dimensions namely the forward, aft perpendicular, midship, moulded drafts, hull and water line coefficient etc.
During the vessel construction stage, the vessel’s draft marks are marked in a convenient position and are very often offset from the exact position of the forward, aft perpendicular or midship.
For calculations purposes, the drafts of the perpendiculars and midship are required so the observed drafts have to be corrected using the below formulas:
where:
Draft_{Per.} – Corrected draft to the relevant perpendicular [m];
Draft_{mark} – Observed draft from forward, mid, aft marks [m];
Corr._{Per.} – Correction of the draft from draft mark to perpendicular [m];
Trim_{obs.} – Observed trim of the vessel [m];
Aft D – Distance from aft draft mark to aft perpendicular (If draft mark is aft from perpendicular the sign is “” if forward “+”) [m];
Mid D – Distance to midship draft mark to midship of the vessel (If draft mark is aft from perpendicular the sign is “” if forward “+”) [m];
Fwd D – Distance from forward draft mark to forward perpendicular (If draft mark is aft from perpendicular the sign is “” if forward “+”) [m];
Trim_{Obs.} – Difference between forward and aft draft (aft trim is “+”, forward trim is ””);
Figure 3. Draft Corrections
2.2.2 The Mean of the Means of the Mean draft
The shape of the vessel’s hull leads to an unbalanced distribution of cargo, ballast, lightship weights and buoyancy of the hull during the different loading condition, which creates deformations known as hogging and sagging. The Hogging effect is most common during ballast passage or partial loading, where the ship will deform as a beam supported at mid length and loaded at the ends. The Sagging is most common for loaded vessel and the hull will curved as a beam supported at the ends and loaded at mid length.
In order to compensate for the effect of the hull deformations and to determine the average midship draft, in the draft survey computation the following approximate mathematical method is used:
where:
Draft_{Fwd} – Corrected to forward perpendicular draft [m];
Draft_{mid} – Corrected to vessel’s midship draft [m];
Draft_{aft} – Corrected to aft perpendicular draft [m];
2.3 Displacement
2.3.1 Displacement at draft
Once the mean of the means of the mean draft is calculated, the relevant vessel’s displacement has to be extracted from the vessel’s hydrostatic tables. The vessel’s hydrostatic tables are based on the moulded draft, which is the draft corrected for the keel thickness, but some tables contained both moulded and external drafts.
Very often the exact draft couldn’t be found directly in the ship’s tables and interpolation, between the two closest drafts, has to be performed.
Figure 4. Typical extract from vessel’s hydrostatic tables
2.3.2 Displacement corrections
2.3.2.1 Trim correction
Due to the uneven shape of the vessel in forward and aft part, at constant average draft a vessel on even keel has bigger displacement than vessel with trim.
Most of the vessels have only one hydrostatic table for even keel and the displacement extracted from it, need to be additionally corrected for trim. In case the vessel’s hydrostatics cover various trim conditions, the exact displacement for actual trim can be found interpolating between the closest one.
2.3.2.1.1 1^{st} correction (Layer Correction)
The physics behind the first correction is that actually the vessel’s is trimmed over a line passing though the Longitudinal center of floatation (LCF) and not about midship. The previously calculated mean draft is adjusted and corrected for midship, so in order to determine the true mean draft additional correction for the distance between LCF and midship section has to be performed.
This correction is similar by nature to the corrections of the draft from the draft mark to perpendiculars and is determined by the following formula:
Where LCF is the distance between the vessel’s midship section and the longitudinal center of floatation. The LCF has to be extracted and interpolated from the hydrostatic tables for the calculated draft and assigned “+” if aft from midship and “” if forward.
Considering the above the true mean draft is the mean of the means of the mean draft corrected with the layer correction.
However, the normal draft survey calculation method corrects the extracted displacement apart from adjusting the draft. In this case the layer correction is calculated in tonnes using the following formula:
2.3.2.1.2 2^{nd} correction (Nemoto’s correction)
The position of the LCF, as specified in the hydrostatic tables, is for even keel condition. The longitudinal center of floatation is by nature the geometric center of the waterplane area. Once the vessel is trimmed, the waterplane area changes due to the nonsymmetrical shape of the vessel’s forward and aft parts, which leads to a change in the LCF position. The 2^{nd} trim correction aims to correct the displacement due to the misplacement of the LCF.
The 2^{nd} trim correction is also calculated in tonnes using the following formula:
d MCTC is the difference in Moment to change trim (MCTC) for 1 meter;
MCTC_{d+50cm} is MCTC for mean adjusted draft + 50 cm;
MCTC_{d50cm} is MCTC for mean adjusted draft – 50 cm;
2.3.2.2. Seawater density
The final correction, which has to be utilized, is for adjusting the displacement for the water density, in which the vessel floats. The water density in different ocean regions around the globe varies widely. Therefore, the value of 1.025 tm/m^{3} has been recognized to be the average seawater density and most of the vessel’s hydrostatic tables are calculated for this standard density.
In order to perform accurate draft survey calculation, a sea water sample has to be taken and actual water density determined using draft survey hydrometer. After the displacement is corrected for trim, it has to be adjusted for the difference in densities using the following formula:
2.4 Ballast water
All ballast water tanks, even those said to be empty, must be carefully sounded or proven to be full by pressing up and overflowing from vent pipes. It is a good practice that the height of the measuring pipe of each ballast tank is noted and checked against the data in the vessel’s drawings/tables.
In order to avoid any mistakes in ballast calculations in case the ballast tanks don’t have a correction for the list, the vessel has to be upright, and if no trim correction available, tanks to be either full or empty.
The density of each ballast tank has to be known, the surveyor can check it in the last discharging port draft survey and/or as noted in the ballast logbook for previous ballast operations.
Calculation of the weight of ballast water is undoubtedly the most usual source of errors, which may result in very large and unacceptable inaccuracies in the cargo quantity.
2.5 Various consumables
In addition to the ballast all other tanks containing consumables like HFO, MDO, Lubrication oil, freshwater, or residuals like bilge, sludge, sewage, etc. have to be checked or quantities taken from the Chief Engineer records.
3. Cargo determination
As mentioned above the net displacements before and after loading/discharging have to be calculated and the difference between them is the cargo loaded/discharged.
The draft survey calculation can be crosschecked by the socalled vessel’s constant. The constant is determined during the surveys by deducting the lightship and the cargo as per the Bill of lading (B/L) from the Net Displacement. The constant includes all unknown weight like – stores and provisions, mud in the ballast tanks, marine growths on the hull, lightship changes, etc.
Considering the nature of the ship’s constant it can be considered permanent for a prolonged period of time and wide variations can be expected only after the vessel’s drydocking or undergoing substantial repairs/modifications.
Comparing the calculated one with the constants, determined during previous draft surveys, will assist in determining any substantial inaccuracies during the draft survey.
